Recessed

RAY Recessed LED Panels Round

Name: RAY Recessed LED Panels Round
Brand: Classic Light
Availability: InStock

Sleek and modern lighting solution for homes and offices. Provides bright, energy-efficient illumination with a clean, minimalist design.

Applications

Residential Lighting

Commercial Design

Educational Institutions

Hospitality

Public Buildings

Industrial Lighting

Full Information

RAY Recessed LED Panels Round is a round recessed LED ceiling panel with edge-lit LED arrangement behind a diffuser, producing uniform low-glare illumination across the face of the fixture.

Available wattages: 3w, 18 w, 22w, 24 w, 3 w, 6w, 9w, 12w. Colour temperature options: 3000k, 6500k, 4000k, 3CCT. Finishes / housing colours: White, Silver, Bronze. Input voltage: 220v. Output: 360 lumens, 2160 lumens, 2200 lumens, 2880 lumens, 600 lumens, 900 lumens, 1200 lumens. Size: 65mm, 200mm, 285mm, 100mm, 125mm, 150mm.

Switchable 3CCT (3000K / 4000K / 6500K) selectable on the fixture

Typical applications: Residential Lighting, Commercial Design, Educational Institutions, Hospitality, Public Buildings, Industrial Lighting.

Product Specifications

Code	Cct	Power	Size	Color	Lumen	Sku	Voltage	Quantity
CL-R003WW	3000k	3w	65mm	White	360 lumens	11220200	220v	100 pcs
CL-R003DL	6500k	3w	65mm	White	360 lumens	11220201	220v	100 pcs
CL-R003NW	4000k	3w	65mm	White	360 lumens	11220202	220v	100 pcs
CL-R103WW	3000k	3w	65mm	Silver	360 lumens	11220203	220v	100 pcs
CL-R103DL	6500k	3w	65mm	Silver	360 lumens	11220204	220v	100 pcs
CL-R103NW	4000k	3w	65mm	Silver	360 lumens	11220205	220v	100 pcs
CL-R203WW	3000k	3w	65mm	Bronze	360 lumens	11220206	220v	100 pcs
CL-R203DL	6500k	3w	65mm	Bronze	360 lumens	11220207	220v	100 pcs
CL-R203NW	4000k	3w	65mm	Bronze	360 lumens	11220208	220v	100 pcs
CL-R018WW	3000k	18 w	200mm	White	2160 lumens	11220218	220v	30 pcs
CL-R018DL	6500k	18 w	200mm	White	2160 lumens	11220219	220v	30 pcs
CL-R018NW	4000k	18 w	200mm	White	2160 lumens	11220220	220v	30 pcs
CL-R118WW	3000k	18 w	200mm	Silver	2160 lumens	11220221	220v	30 pcs
CL-R118DL	6500k	18 w	200mm	Silver	2160 lumens	11220222	220v	30 pcs
CL-R118NW	4000k	18 w	200mm	Silver	2160 lumens	11220223	220v	30 pcs
CL-R0218WW	3000k	18 w	200mm	Bronze	2160 lumens	11220224	220v	30 pcs
CL-R0218DL	6500k	18 w	200mm	Bronze	2160 lumens	11220225	220v	30 pcs
CL-R0218NW	4000k	18 w	200mm	Bronze	2160 lumens	11220226	220v	30 pcs
CL-R2022CT	3CCT	22w	200mm	White	2200 lumens	11220230	220v	30 pcs
CL-R024CT	3CCT	24 w	285mm	White	2880 lumens	11220231	220v	20 pcs
CL-R003CT	3CCT	3 w	65mm	White	360 lumens	11220232	220v	100 pcs
CL-R006CT	3CCT	6w	100mm	White	600 lumens	11220233	220v	100 pcs
CL-R009CT	3CCT	9w	125mm	White	900 lumens	11220234	220v	40 pcs
CL-R012CT	3CCT	12w	150mm	White	1200 lumens	11220235	220v	40 pcs
